▌External Bypass Soft Starter Advanced Features:

• Reduced Motor Stress,Minimizes mechanical stress on the motor during startup and stopping.

• Enhanced Motor Life,Protects the motor from damage caused by inrush currents and voltage spikes.

• Improved Energy Efficiency, Optimizes motor operation for energy savings.

• Reliable Operation, Ensures consistent and reliable performance.

• Easy Installation and Maintenance, Simple to install and maintain.

▌External Bypass Soft Starter Characteristics:

• Modular Design:
  Requires additional components like circuit breakers (for short-circuit protection) and AC contactors (for bypassing) to be installed within the cabinet, along with switches to complete the motor control circuit.

• Advanced Motor Protection:
  Eliminates the need for thermal relays by providing comprehensive motor protection during startup and operation.

• Closed-Loop Control:
  Ensures smooth and reliable soft starts and stops, improving motor performance and reliability.

• Low Power Consumption:
  Utilizes a bypass contactor during normal operation, minimizing power consumption and enhancing system efficiency.

• Intelligent Control:
  Features advanced control algorithms for precise motor control.

• Versatile Starting Modes:
  6 Start  and 2 Stop Mode

▌Protection Function:

Phase Loss Protection:
When any one of the three phases is open-circuited, the protection action time is less than 1 minute.
Phase Imbalance Protection:
When the three-phase imbalance K1 or K2 is greater than 10%, the protection action time is less than 10 minutes.
Overcurrent Protection:
When the motor is stalled, the protector operates with a delay of (±1s).
Overvoltage Protection:
When the power supply voltage Ue > 120%, the protection action time is less than 1 second.
Undervoltage Protection:
When the power supply voltage is (60%-75%) Ue, the protection action time is less than 60 seconds.
Reset Function:
Manual reset via the stop button.
Overtemperature Protection:
When the soft starter operates at an excessive temperature, the soft starter will automatically shut down and report a soft start overheat fault.

▌Application Range:

• Fluid Handling (Pumps & Fans):
  Used in water treatment, HVAC, and industrial ventilation to minimize mechanical stress and improve energy efficiency during startup.

• Material Transport (Conveyors & Belt Drives):
  Ensures gradual motor speed increase, reducing equipment wear and enhancing operational efficiency.

• Compression Systems (Compressors):
  Reduces inrush current and mechanical stress in air conditioning, refrigeration, and industrial compressor applications.

• Mixing & Agitation (Mixers & Agitators):
  Provides smooth, controlled startups in food processing, chemical facilities, and wastewater treatment, minimizing vibration and improving efficiency.

• Size Reduction (Crushers & Mills):
  Used in mining, cement, and aggregate processing to decrease mechanical stress and enhance energy efficiency.

▌Environmental requirements:
If the altitude exceeds 1000 meters, the capacity should be reduced accordingly. For every 100 meters increase above 1000 meters, the current should be reduced by 0.5%; The relative humidity should not exceed 95% when the ambient temperature is between -10 ℃ and+40 ℃; No condensation, no flammable and explosive gases, no conductive dust, in a well ventilated indoor environment
